Fronus PV 7200 (Infineon Reborn) 6KW IP21 Single Phase Hybrid Solar Inverter Price in Pakistan

DescriptionUpgraded MPPT Chipset (upgraded to the latest chipset that is more efficient and reliable)Control with Wi-Fi (Control inverter remotely with mobile application)Anti-dust kit protects inverter from dust particles120 Ampere max PV chargingLithium-ion battery compatiblePure sine Wave (Produce smooth waveform)Fronus PV 7200 Infineon Reborn DatasheetModelFronus 6KW Hybrid InverterMaximum PV Input Power7200WattRated Output Power6200W/6200VAOutput Voltage WaveformPure Sine WaveOutput Voltage Regulation230VAC ±5%Output Frequency50HzPeak Efficiency93%Overload Protection3s@≥150% Load 5s@100%~150 LoadSurge Capacity12400 Watt for 5sNominal DC Input Voltage48VdcCold Start Voltage46VdcHigh DC Recovery Voltage62vdcHigh DC Cut-Off Voltage63VdcNo Load Power Consumption50WFull Load6200WMaximum Main Load6200WMaximum Second Load Upto(Battery Mode)2066WMain Load Cutt-Off Voltage52VDCMain Load Return Voltage54VDCCharging Algorithm3-StepAC Charging Current (Maximum)100A (@V1/P = 230Vac)Bulk Charging VoltageFlooded Battery AGM/Gel Battery58.4 56.4Floating Charging Voltage54VdcMaximum PV Array Power7200WNominal PV Voltage360VdcPV Array MPPT Voltage Range60Vdc~400VdcMax PV Array Open Circuit Voltage500VdcMaximum Charging Current120ANominal Output Voltage220/230/240VACFeed-In Grid Voltage Range195!253VACFeed-In Grid Frequency Range49~51±1Hz / 59~61±1HzNominal Output Current26.9APower Factor Range>99Maximum Conversion Efficiency (DC/AC)97%Input Voltage WaveformSinusoidal (Utility or Generator)Nominal Input Voltage230VacLow Loss Voltage170Vac ±7V (UPS) 90Vac ±7V (Appliances)Low Loss Return Voltage180Vac ±7V (UPS) 100Vac ±7V (Appliances)High Loss Voltage280Vac±7VHigh Loss Return Voltage270Vac±7VMaximum AC Input Voltage300VacNominal Input Frequency50Hz / 60Hz (Auto Detection)Low Loss Frequency40±1HzLow Loss Return Frequency42±1HzHigh Loss Frequency65±1HzHigh Loss Return Frequency63±1HzOutput Short Circuit ProtectionCircuit BreakerEfficiency (Line Mode)>95% (Rated R Load, Battery Full Charged)Transfer Time10ms For UPS 20ms For ApplianceSafety CertificationCEOperating Temperature Range-10˚C to 50˚CStorage Temperature-15˚C to 60˚CHumidity5% to 95% Relative Humidity (Non-Condensing)Dimensions (D*W*H) mm450*350*120Net Weight (KG)10 KG
